Freescale Semiconductor, Inc.
Enhanced Capture Timer
Timer Registers
BIT 7
6
PBEN
0
5
0
0
4
0
0
3
0
0
2
0
0
1
PBOVI
0
BIT 0
0
0
0
RESET:
0
PBCTL — 16-Bit Pulse Accumulator B Control Register
$00B0
Read: any time
Write: any time
16-Bit Pulse Accumulator B (PACB) is formed by cascading the 8-bit
pulse accumulators PAC1 and PAC0.
When PBEN is set, the PACB is enabled. The PACB shares the input
pin with IC0.
PBEN — Pulse Accumulator B System Enable
0 = 16-bit Pulse Accumulator system disabled. 8-bit PAC1 and
PAC0 can be enabled when their related enable bits in
ICPACR ($A8) are set.
1 = Pulse Accumulator B system enabled. The two 8-bit pulse
accumulators PAC1 and PAC0 are cascaded to form the
PACB 16-bit pulse accumulator. When PACB in enabled, the
PACN1 and PACN0 registers contents are respectively the
high and low byte of the PACB.
PA1EN and PA0EN control bits in ICPACR ($A8) have no
effect.
PBEN is independent from TEN. With timer disabled, the pulse
accumulator can still function unless pulse accumulator is disabled.
PBOVI — Pulse Accumulator B Overflow Interrupt enable
0 = interrupt inhibited
1 = interrupt requested if PBOVF is set
MC68HC912DG128 — Rev 3.0
Technical Data
Enhanced Capture Timer
