PACMX — 8-Bit Pulse Accumulators Maximum Count
0 = Normal operation. When the 8-bit pulse accumulator has
reached the value $FF, with the next active edge, it will be
incremented to $00.
1 = When the 8-bit pulse accumulator has reached the value $FF,
it will not be incremented further. The value $FF indicates a
count of 255 or more.
BUFEN — IC Buffer Enable
0 = Input Capture and pulse accumulator holding registers are
disabled.
1 = Input Capture and pulse accumulator holding registers are
enabled. The latching mode is defined by LATQ control bit.
Write one into ICLAT bit in MCCTL ($A6), when LATQ is set
will produce latching of input capture and pulse accumulators
registers into their holding registers.
LATQ — Input Control Latch or Queue Mode Enable
The BUFEN control bit should be set in order to enable the IC and
pulse accumulators holding registers. Otherwise LATQ latching
modes are disabled.
Write one into ICLAT bit in MCCTL ($A6), when LATQ and BUFEN
are set will produce latching of input capture and pulse accumulators
registers into their holding registers.
0 = Queue Mode of Input Capture is enabled.
The main timer value is memorized in the IC register by a valid
input pin transition.
With a new occurrence of a capture, the value of the IC register
will be transferred to its holding register and the IC register
memorizes the new timer value.
1 = Latch Mode is enabled. Latching function occurs when
modulus down-counter reaches zero or a zero is written into
the count register MCCNT (see Buffered IC Channels).
With a latching event the contents of IC registers and 8-bit
pulse accumulators are transferred to their holding registers.
8-bit pulse accumulators are cleared.
