Model No.：FYLS-3528RGBC-CA
Solder=Sn63-Pb37
Solder= Pb-Free
Average ramp-up rate:4℃/sec.max
Peak preheat temperature:100-150℃
preheat time:100seconds.max
Average ramp-up rate:4℃/sec.max
Peak preheat temperature:100-150℃
preheat time:100seconds.max
ramp-down rate:6℃/sec.max
Peak temperature:230℃
ramp-down rate:6℃/sec.max
Peak temperature:250℃
Time within 5℃ of actual peak temperature=10 Time within 5℃ of actual peak temperature=10 sec.
sec. max
max
Duration above 183℃ is 80 sec. max
Duration above 217℃ is 80 sec. max
SMD LED should not be modified after soldering. If modification cannot be avoided, the modification
must be pre-qualified to avoid damage to the SMD LEDs.
Reflow soldering should not be done more than one time
No stress should be exerted on the package during soldering.
(3) Recommend Soldering pad design(unit=mm)
3. Static Electricity
Static Electricity and surge voltage damage the LEDs. So it is recommended that an ESD wrist band,
ESD shoe strap or an anti-electrostatic glove be used when handling the LEDs.
All devices, equipment and machinery must be properly grounded
4. Others
Reverse voltage should not exceed the absolute maximum rating on the data sheet. The colour of the LEDs
is changed slightly an operating current and thermal.
This device should not be used in any type of fluid such as water, oil, organic solvent and etc
When washing is required, IPA (Isopropyl Alcohol) should be used.
The influence of ultrasonic cleaning on the leds depends on factors such as ultrasonic power and the way.
High-brightness LED light may injure human eyes. Avoid looking directly into lighted LED
The appearance and specifications of the product may be modified for improvement without notice.
