FM25Q64ꢀ
ꢀ
11.2.17ꢀ32KBꢀBlockꢀEraseꢀ(52h)ꢀ
TheꢀBlockꢀEraseꢀinstructionꢀsetsꢀallꢀmemoryꢀwithinꢀaꢀspecifiedꢀblockꢀ(32kꢁbytes)ꢀtoꢀtheꢀerasedꢀstateꢀ
ofꢀallꢀ1sꢀ(FFh).ꢀAꢀWriteꢀEnableꢀinstructionꢀmustꢀbeꢀexecutedꢀbeforeꢀtheꢀdeviceꢀwillꢀacceptꢀtheꢀBlockꢀ
EraseꢀInstructionꢀ(StatusꢀRegisterꢀbitꢀWELꢀmustꢀequalꢀ1).ꢀTheꢀinstructionꢀisꢀinitiatedꢀbyꢀdrivingꢀtheꢀ
/CSꢀpinꢀlowꢀandꢀshiftingꢀtheꢀinstructionꢀcodeꢀ“52h”ꢀfollowedꢀaꢀ24ꢁbitꢀblockꢀaddressꢀ(A23ꢁA0).ꢀTheꢀ
BlockꢀEraseꢀinstructionꢀsequenceꢀisꢀshownꢀinꢀfigureꢀ17.ꢀ
ꢀ
Theꢀ/CSꢀpinꢀmustꢀbeꢀdrivenꢀhighꢀafterꢀtheꢀeighthꢀbitꢀofꢀtheꢀlastꢀbyteꢀhasꢀbeenꢀlatched.ꢀIfꢀthisꢀisꢀnotꢀ
doneꢀtheꢀBlockꢀEraseꢀinstructionꢀwillꢀnotꢀbeꢀexecuted.ꢀAfterꢀ/CSꢀisꢀdrivenꢀhigh,ꢀtheꢀselfꢁtimedꢀBlockꢀ
EraseꢀinstructionꢀwillꢀcommenceꢀforꢀaꢀtimeꢀdurationꢀofꢀtBE1ꢀ(SeeꢀACꢀCharacteristics).ꢀWhileꢀtheꢀ
BlockꢀEraseꢀcycleꢀisꢀinꢀprogress,ꢀtheꢀReadꢀStatusꢀRegisterꢀinstructionꢀmayꢀstillꢀbeꢀaccessedꢀforꢀ
checkingꢀ theꢀ statusꢀ ofꢀ theꢀ BUSYꢀ bit.ꢀ Theꢀ BUSYꢀ bitꢀ isꢀ aꢀ 1ꢀ duringꢀ theꢀ Blockꢀ Eraseꢀ cycleꢀ andꢀ
becomesꢀaꢀ0ꢀwhenꢀtheꢀcycleꢀisꢀfinishedꢀandꢀtheꢀdeviceꢀisꢀreadyꢀtoꢀacceptꢀotherꢀinstructionsꢀagain.ꢀ ꢀ
AfterꢀtheꢀSectorꢀEraseꢀcycleꢀhasꢀfinishedꢀtheꢀWriteꢀEnableꢀLatchꢀ(WEL)ꢀbitꢀinꢀStatusꢀRegisterꢀisꢀ
clearedꢀtoꢀ0.TheꢀBlockꢀEraseꢀinstructionꢀwillꢀnotꢀbeꢀexecutedꢀifꢀtheꢀaddressedꢀpageꢀisꢀprotectedꢀbyꢀ
theꢀ Blockꢀ Protectꢀ (SEC,ꢀ TB,ꢀ BP2,ꢀ BP1,ꢀ andꢀ BP0)ꢀ bitsꢀ (seeꢀ Statusꢀ Registerꢀ Memoryꢀ Protectionꢀ
table).ꢀ
ꢀ
ꢀ
Figureꢀ17.ꢀ32KBꢀBlockꢀEraseꢀInstructionꢀSequenceꢀDiagramꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
ꢀ
preliminary(Aug.18.2010)ꢀ ꢀ ꢀ ꢀ
33ꢀ
