FM25Q64ꢀ
ꢀ
11.2.15ꢀQuadꢀPageꢀProgramꢀ(38h)ꢀ
Theꢀ Quadꢀ Pageꢀ Programꢀ instructionꢀ allowsꢀ 24ꢁbitꢀ addressꢀ andꢀ upꢀ toꢀ 256ꢀ bytesꢀ ofꢀ dataꢀ toꢀ beꢀ
programmedꢀatꢀpreviouslyꢀerasedꢀ(FFh)ꢀmemoryꢀlocationsꢀusingꢀfourꢀpins:ꢀIO0,ꢀIO1,ꢀIO2ꢀandꢀIO3.ꢀ
TheꢀQuadꢀPageꢀProgramꢀcanꢀimproveꢀperformanceꢀforꢀPROMꢀProgrammerꢀandꢀapplicationsꢀthatꢀ
haveꢀslowꢀclockꢀspeedꢀ<5MHz.ꢀSystemꢀwithꢀfasterꢀclockꢀspeedꢀwillꢀnotꢀrealizeꢀmuchꢀbenefitꢀforꢀtheꢀ
QuadꢀPageꢀProgramꢀinstructionꢀsinceꢀtheꢀinherentꢀpageꢀprogramꢀtimeꢀisꢀmuchꢀgreaterꢀthanꢀtheꢀ
timeꢀitꢀtakesꢀtoꢀclockꢁinꢀtheꢀdata.ꢀ
ꢀ
ToꢀuseꢀQuadꢀPageꢀProgramꢀtheꢀQuadꢀEnableꢀinꢀStatusꢀRegisterꢁ2ꢀmustꢀbeꢀsetꢀ(QE=1),ꢀAꢀWriteꢀ
Enableꢀ instructionꢀ mustꢀ beꢀ executedꢀ beforeꢀ theꢀ deviceꢀ willꢀ acceptꢀ theꢀ Quadꢀ Pageꢀ Programꢀ
instructionꢀ(StatusꢀRegisterꢁ1,ꢀWEL=1).ꢀTheꢀinstructionꢀisꢀinitiatedꢀbyꢀdrivingꢀtheꢀ/CSꢀpinꢀlowꢀthenꢀ
shiftingꢀtheꢀinstructionꢀcodeꢀ“38h”ꢀfollowedꢀbyꢀaꢀ24ꢁbitꢀaddressꢀ(A23ꢁA0)ꢀandꢀatꢀleastꢀoneꢀdata,ꢀintoꢀ
theꢀIOꢀpins.ꢀTheꢀ/CSꢀpinꢀmustꢀbeꢀheldꢀlowꢀforꢀtheꢀentireꢀlengthꢀofꢀtheꢀinstructionꢀwhileꢀdataꢀisꢀbeingꢀ
sentꢀtoꢀtheꢀdevice.ꢀAllꢀotherꢀfunctionsꢀofꢀQuadꢀPageꢀProgramꢀareꢀidenticalꢀstandardꢀPageꢀProgram.ꢀ
TheꢀQuadꢀPageꢀProgramꢀinstructionꢀsequenceꢀisꢀshownꢀinꢀfigureꢀ15.ꢀ
ꢀ
ꢀ
