XRT86L30
SINGLE T1/E1/J1 FRAMER/LIU COMBO
REV. 1.0.1
FIGURE 73. INTERFACING XRT86L30 RECEIVE TO LOCAL TERMINAL EQUIPMENT USING 16.384MBIT/S, HMVIP
16.384MBIT
/S
,
AND H.100 16.384MBIT/S
XRT86L30
Transmit
RxSER0
Payload
Data Input
Interface
Chn 0
RxSERCLK0 (16.384MHz)
RxSYNC0
RxLineClk0 (2.048MHz)
Terminal
Equipment
Figure 74 shows the waveforms for connecting the Transmit multiplexed high-speed Input Interface block to
local Terminal Equipment. Figure 75 shows the waveforms for connecting the Receive multiplexed high-
speed Input Interface block to local Terminal Equipment for HMVIP. Figure 76 shows the waveforms for
203
