AT commands
I/O settings commands
M1 (PWM1 Duty Cycle)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
The duty cycle of the PWM1 line (TH pin 7/SMT pin 8).
Use the P1 command to configure the line as a PWM output.
Before setting the line as an output:
1. Enable PWM1 output (P1 = 2).
2. Apply settings (use CN or AC)
Parameter range
0 - 0x3FF
Default
0
P5 (SPI_MISO)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Sets or displays the SPI_MISO configuration.
This only applies to surface-mount devices.
Parameter range
0, 1
Parameter
Description
Disabled
0
1
SPI_MISO
Default
1
P6 (SPI_MOSI Configuration)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Sets or displays the SPI_MOSI configuration.
This only applies to surface-mount devices.
Parameter range
0, 1
Parameter
Description
Disabled
0
1
SPI_MOSI
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
96
