AT commands
I/O settings commands
Parameter
Description
Disabled
0
0
1
2
3
4
5
Unmonitored digital input
N/A
ADC
Digital input
Digital output, low
Digital output, high
Default
0
D1 (DIO1/AD1)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Sets or displays the DIO1/AD1 configuration (TH pin 19/SMT pin 32).
Parameter range
Parameter
Description
0
1
1
2
3
4
5
6
Disabled
Commissioning button
SPI_ATTN for the through-hole device
ADC
Digital input
Digital output, low
Digital output, high
PTI_EN
Default
0
D2 (DIO2/AD2)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Sets or displays the DIO2/AD2 configuration (TH pin 18/SMT pin 31).
Parameter range
0 - 5
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
91
