AT commands
Diagnostic commands
T7 (D7 Output Timeout)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Specifies how long pin D7 holds a given value before it reverts to configured value. If set to 0, there is
no timeout.
Parameter range
0 - 0xFF (x 100 ms)
Default
0xFF
PT (PWM Output Timeout)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Specifies how long both PWM outputs (P0, P1) output a given PWM signal before it reverts to the
configured value (M0/M1). If set to 0, there is no timeout. This timeout only affects these pins when
they are configured as PWM output.
Parameter range
0 - 0xFF (x 100 ms)
Default
0xFF
Diagnostic commands
The following AT commands are diagnostic commands. Diagnostic commands are typically volatile
and will not persist across a power cycle.
VR (Firmware Version)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Reads the firmware version on a device.
Firmware version numbers have four significant digits. The reported number shows three or four
numbers in hexadecimal notation. A version is reported as ABCD. Digits ABC are the main release
number and D is the revision number from the main release. D is not required and if it is not present, a
zero is assumed for D. B is a variant designator.
Parameter range
0x2000 - 0x20FF
Default
Set in the factory
VL (Version Long)
This command applies to the XBee/XBee-PRO S2C 802.15.4 RF Module.
Shows detailed version information including the application build date and time.
XBee/XBee-PRO S2C 802.15.4 RF Module User Guide
104
