Wirewound Anti-Surge Resistor
Type EP Series
Key Features
n Power up to 10W in
Small Size
n 16 Size/Power Options
n Specially Designed and
Tested for Surge Immunity
n Flame Resistant Coating
TE Connectivity is pleased to offer this wire wound axial leaded resistor. Robustly manufac-
tured with high quality materials this resistor offers flame proof coating, and is designed and
tested to withstand power surges of up to 12KV.
Characteristics – Electrical
Type
Ratedꢀ
Power
atꢀ70°ꢀC
Max.ꢀ
Working
Voltage
Max. Dielectric
Overload Withstanding
Resistance
Range
Operating
Temp.ꢀ
Range
Voltage
Voltage
Normal EP05W
size
1/2W
(0.50W)
500 V
1,000 V
350 V
10Ω560Ω
EP1W
EP2W
EP3W
EP5W
EP7W
EP8W
EP9W
1W
2W
3W
5W
7W
8W
9W
1W
2W
3W
5W
7W
8W
9W
10W
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
1,000 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
500 V
10Ω1KΩ
10Ω2KΩ
10Ω3KΩ
10Ω5KΩ
10Ω6KΩ
10Ω10KΩ
10Ω15KΩ
10Ω560Ω
10Ω1KΩ
10Ω2KΩ
10Ω3KΩ
10Ω5KΩ
10Ω6KΩ
10Ω10KΩ
10Ω15KΩ
-55℃ –
+155℃
Small
size
EP1WS
EP2WS
EP3WS
EP5WS
EP7WS
EP8WS
EP9WS
EP10WS
-55℃ –
+155℃
Power Derating Curve
+70 °C
+155 °C
+275 °C
100
80
60
40
20
0
-55
0
50
100 150 200 250 300
AmbientꢀTemperatureꢀ(°C)
For resistors operated in ambient temperatures above 70°C, power rating must be derated in accordance with this curve.
9-1773463-6 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
