AU6989SN-GT USB2.0 Universal Flash Disk Controller V1.00
1. Introduction
1.1 Description
The AU6989SN-GT (embedded Crystal) USB 2.0 Flash Disk Controller is the best
high performance solutions for MLC, TLC SDR/DDR NAND flash with multiple dies
data flash. AU6989SN-GT designs embedded crystal with Alcor’s patent and it has
72bit/1K BCH ECC engines to correct high error bits of new generation flash (1x/1y
nm) and provide the well performance for TLC flash especial DDR flash.
AU6989SN-GT provides dual channel access and ISP (In-System Programming)
technologies with Alcor’s patent, which are the most important features to allow
manufacturers building high performance UFD easily and to have the flexibility of
adopting different source of flash chips.
To enhance the usefulness and manageability of UFD further, Alcor Micro develops a
smart application program iStar (Partition/Password Operation Tool) as a handy utility
in managing partition, password and security. Having iStar as the companion of UFD,
the data in a UFD could be protected from unauthorized access successfully.
1.2 Features
ꢀ PCBs are pin compatible with AU69XX USB2.0 series
ꢀ Integrated build-in Regulator
ꢀ Integrated build-in Crystal with Alcor’s patent
ꢀ Supports 72bit/1K BCH ECC engines
ꢀ Supports new generation MLC/TLC flash
ꢀ Supports Toggle/ONFI DDR flash
ꢀ Not support the flash ECC requirement under 24bit/1K
ꢀ Well performance in TLC DDR flash
ꢀ Improved read performance reach 32MB/Sec
ꢀ Integrates hardware DMA engine to tune up the operation performance
ꢀ Works with default driver under the environments of Windows ME, Windows
2000, Windows XP, Vista, Window7, Windows 8, Mac 9.2, Mac OS 10.x. Using
Alcor Micro’s vendor driver for the environment under Windows 98SE
ꢀ Low power operation with SDR/DDR flash
ꢀ Supports software write protection
ꢀ Support Auto Run function
6
