High Speed Backplane Connectors
Connector Selection Grid for VITA 46 VPX Compliant Connectors (Continued)
VITA 46 VPX
Compliant Connectors
Keying Guide
Module
Keying Guide Pin
Part Number
Part Number
1-1469492-X
1-1469491-X
P0
Left End
Half Module
Part Number
1410189-3
Utility
J0
Left End
Half Module
Part Number
1410186-1
J1
P1
Center Module
Center Module
Part Number
1410187-3
Part Number
1410140-1
Differential
J2
Right End
Module
Part Number
1410142-1
P2
Center Module
Part Number
1410187-3
Differential
or
Part Number
1410190-3
Single-Ended
(5:2)
Keying Guide Pin
Part Number
1-1469491-X
Keying Guide
Module
Part Number
1-1469492-X
J3
Center Module
Part Number
1410140-1
P3
Center Module
Part Number
1410187-3
Differential
or
Part Number
1410190-3
Single-Ended
(5:2)
J4
5
Center Module
Part Number
1410140-1
J5
Center Module
Part Number
1410140-1
P4
Center Module
Part Number
1410187-3
Differential
or
Part Number
1410190-3
Single-Ended
(5:2)
J6
Right End Module
Part Number
1410142-1
P5
Center Module
Part Number
1410187-3
Differential
or
Part Number
1410190-3
Single-Ended
(5:2)
Keying Guide Pin
Part Number
1-1469491-X
P6
Center Module
Part Number
1410187-3
Differential
or
Daughtercard
Backplane
Part Number
1410190-3
Single-Ended
(5:2)
Keying Guide
Module
Part Number
1-1469492-X
