ES9023 Product Brief
FUNCTIONAL BLOCK DIAGRAM
Control/Status
ES9023
BCK
2Vrms
Op-Amp
Driver
LRCK
AOUTL
PCM
Interface
Oversampling
Filter
Jitter
Reduction
HyperStream
DAC (2x)
SDI
AOUTR
(2x)
MCLK
Power Supply &
Charge Pump
VEE
APPLICATION DIAGRAM
Blu-Ray Player
AVCC
L
DVD Player
Audio
Audio Out
Processor
(2Vrms)
ES9023
R
Home Theater Receiver
PC Pro-Audio Sound Card
