Limited Internal
E
EBAOCMA
PRODUCT SPECIFICATION
1 (5)
Prepared (also subject responsible if other)
No.
2/1301-BMR 637 02/2 Uen
4
Technical Specification
Approved
Checked
Date
Rev
Reference
EN/LZT 146 306 R4A July 2008
PKM 4000D PINB Series
DC/DC converters, Input 36-75 V, Output 40 A/132 W
SEC/D (Kevin Zhou)
MICOSPE
2006-11-22
A
© Ericsson Power Modules AB
Absolute Maximum Ratings
Characteristics
min
-40
typ
max
+110
+125
+80
Unit
°C
°C
V
Tref
TS
Operating Temperature (see Thermal Consideration section)
Storage temperature
-55
VI
Input voltage
-0.5
Viso
Viso
Vtr
Isolation voltage baseplate (input to output, input & output to baseplate test voltage)
Isolation voltage no baseplate option (input to output)
Input voltage transient (Tp 100 ms)
1500
1500
100
Vdc
Vdc
V
Positive logic option
Negative logic
-0.5
-0.5
-0.5
+15
V
Remote Control pin voltage
(see Operating Information section)
VRC
Vadj
+15
V
Adjust pin voltage (see Operating Information section)
+5
V
Stress in excess of Absolute Maximum Ratings may cause permanent damage. Absolute Maximum Ratings, sometimes referred to as no destruction limits, are
normally tested with one parameter at a time exceeding the limits of Output data or Electrical Characteristics. If exposed to stress above these limits, function and
performance may degrade in an unspecified manner.
Fundamental Circuit Diagram
Isolated
Feedback
+ Out
Primary
Secondary
+ In
+ Out
+ Sense
Vadj
Voltage
Monitoring
RC
- In
Control
Control
- Sense
- Out
- Out
