GRAPHICS
S1D13506
■ DESCRIPTION
Memory Interface
Digital Video Camera Interface
• 16-bit EDO-DRAM or FPM-DRAM interface.
• Built-in WINNOV Videum® Cam digital camera interface.
• Addressable as a single linear address space.
Display Modes
• 4/8/16 bit-per-pixel (bpp) support on LCD, CRT andTV.
CPU Interface
• Supports the following interfaces:
• Up to 64 shades of gray on monochrome LCD panels using
EPSON E0C33
Hitachi SH-4/SH-3
ISA bus
Motorola M68xxx
Motorola MPC821
NEC MIPS VR41xx
PC Card (PCMCIA)
Philips MIPS PR31500/PR31700
StrongARM (PC Card)
Toshiba MIPS TX39xx
FRM and Dithering.
• Up to 64K colors on passive LCD, active matrix TFT/D-TFD,
CRT and TV in 16 bpp modes.
• SwivelView™: 90°, 180°, 270° hardware rotation of displayed
MPU with programmable READY
image.
• CPU Write buffer.
Display Support
• EPSON Independent Simultaneous Display (EISD): displays
different images on different displays.
• LCD Panels: 4/8/16-bit passive LCD interface.
• Virtual Display Support: displays images larger than the panel
9/12-bit TFT/D-TFD.
size through the use of panning and scrolling.
18-bit TFT/D-TFD to a depth of 64K colors.
• Hardware Cursor or full screen Ink Layer.
• CRT:
• TV:
Embedded RAMDAC for direct analog CRT.
Acc•ele2rDatEionngine including the following BitBLTs:
Composite/S-Video TV output.
NTSC/PAL support.
Flicker filter.
Write BLT
Solid Fill
Move BLT
Pattern Fill
Luminance filter.
Chrominance filter.
Transparent Write BLT Transparent Move BLT
Read BLT Color Expansion
Move BLT with Color Expansion
• Maximum resolution of 800x600 at 16 bpp.
Power Down Modes
Ope•ra2ti.n7gvoVltoslttaog5e.5 volts.
• Software initiated power save mode.
• LCD Power Sequencing.
Package
• 128-pin QFP15.
.
CONTACT YOUR SALES REPRESENTATIVE FOR THESE COMPREHENSIVE DESIGN TOOLS
• S1D13506 Technical Manual • QNX Photon Display Driver
• S5U13506 Evaluation
Boards
• VXWorks UGL and WindML
Display Drivers
• CPU Independent Software • Windows CE Display Driver
Utilities
