Pressure load diagram
Dimensions
All specifications in mm
30
30
Permanent
1000
800
600
400
200
0
104
46
12
A
160
Ø6
0
500
700
900
1100
1300
1500
Stroke / mm
Technical data
Approvals / Certificates
Find out about permission details from your D+H Partner
Supply
24 V DC / 15 ꢀ / 2 ꢁ
30 ꢀ
Duty cycle
EN 12101-2
Force of pressure
Tensile force
800 N
G 500001
800 N
Nominal locking force
Service life
1100 N
20000 double strokes *
7.1 mm/s
Article also available with the following permissions under other article
numbers. Technical data may deviate.
OPEN running speed
OPEN running speed ‑ HS
CLOSED running speed
Type of protection
Emission sound pressure level
Temperature range
Fire resistance
17 mm/s
7.1 mm/s
C
US
IP 65
Lpꢁ ≤ 70 dB(ꢁ)
‑5 °C ... +75 °C
B300 (30 min / 300 °C)
ꢁluminium / Polycarbonate
Powder‑coated
Housing
Surface
Colour
White aluminium (~ RꢁL 9006)
2.5 m silicone cable
Connection
* For vertical use, please consult with D+H Sales!
Design
Type
ꢁrt. No.
Stroke
Dimension ꢁ
Weight
Remark
Zꢁ‑0800‑0600‑1‑PLP‑R HS
Zꢁ‑0800‑0800‑1‑PLP‑R HS
Zꢁ‑0800‑1000‑1‑PLP‑R HS
Zꢁ‑1‑PLP
27.006.05
27.006.10
27.006.15
27.005.00
600 mm
800 mm
1000 mm
762 mm
962 mm
1162 mm
2.10 kg
2.40 kg
2.70 kg
Without holes on bottom, only for topside mounting
Without holes on bottom, only for topside mounting
Variable equipment possible
Brackets are not included and have to be ordered separately.
Status 01/2018
DH [ D+H Mechatronic AG ]
