80
8Bit Single Chip Microcontroller
DMC73C168
VE 0 3FFF 4
; VE : Blank Check, >0 : Device Start Address
; >3FFF : Device end Address, 4: ROM Size = 16K Byte,
VPP = 13.0V (TMX73CE168 : 0000H - 3FFFH)
; 0000H - 3FFFH (C000H - FFFFH) ; DV 4 16K
;
If error happen, try again from Step 7.
STEP 7) Program Device
PE 6 3FFF C006 4 ; TMX73CE168
; PE : Program OTP, >6 : Device Start Address
; >3FFF : Device End Address, 4 ; ROM Size = 16K Byte,
; VPP = 13.0V
STEP 8) Compare Device with your MPO File.
If error happen, try again from Step 7.
STEP 9) Take off Adapter Sock from EPROM Sock on EVM.
If you want to program another device, you have to do repeatedly from Step 5 to Step 9.
If you use EVM73C00A (Not EVM73C00), you may use below "One Line" batch
command.
STEP 6-1) Enter "AU" : Batch Command for VE & PE & CE
AU <CR>
Then VE, PE, SE operations are automatically operated, and displayed below line
in monitor.
VE
PE
CE
ANOTHER DEVICE (Y/N) ?
If you want to program another device (OTP) continuously, change device with new one in
OTP Writer Board and type "Y". When you type "N", This process goes to end.
* Important
- If you replace programmed device with new device on EVM Power On, some error may happen
in access to EPROM area on TMX73CE168 because VCC of EPROM Socket is still asserted.
In case of this mentioned error, if you don't want to do repeatedly from Step 1, get rid of adapter
sock from EVM and then insert adapter socket to EVM again.
DAEWOO ELECTRONICS CO., LTD.
DAEWOO [ DAEWOO Electronic Components ]
