15.5 WLAN 5 GHz Receiver Performance Specifications
Note: The specifications in Table 31 are specified at the RF port unless otherwise specified. Results with FEMs that are not on the
Cypress AVL are not guaranteed.
Table 31. WLAN 5 GHz Receiver Performance Specifications
Parameter
Frequency range
Condition/Notes
Min.
4900
Typ.
Max.
5845
Unit
MHz
–
–
SISO RX sensitivity IEEE 802.11a
(10% PER for 1000 octet PSDU)a
6 Mbps OFDM
9 Mbps OFDM
12 Mbps OFDM
18 Mbps OFDM
24 Mbps OFDM
36 Mbps OFDM
48 Mbps OFDM
54 Mbps OFDM
6 Mbps OFDM
9 Mbps OFDM
12 Mbps OFDM
18 Mbps OFDM
24 Mbps OFDM
36 Mbps OFDM
48 Mbps OFDM
54 Mbps OFDM
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–94.5
–93.2
–91.3
–89.1
–85.7
–82.4
–78.0
–76.6
–95.7
–95.6
–94.1
–92.1
–89.0
–85.7
–81.2
–79.9
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
MIMO RX sensitivity IEEE 802.11a
(10% PER for 1024 octet PSDU)a
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
SISO RX sensitivity IEEE 802.11n
(10% PER for 4096 octet PSDU)a
Defined for default parameters: GF, 800
ns GI, LDPC coding, and non-STBC.
20 MHz channel spacing for all MCS rates
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
–
–
–
–
–
–
–
–
–93.3
–90.9
–88.7
–86.1
–82.5
–78.4
–76.9
–75.1
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
MIMO RX sensitivity IEEE 802.11n
(10% PER for 4096 octet PSDU)a
Defined for default parameters: GF, 800
ns GI, LDPC coding, and non-STBC.
20 MHz channel spacing for all MCS rates
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
MCS8
MCS15
–
–
–
–
–
–
–
–
–
–
–95.8
–93.8
–91.4
–88.7
–85.6
–81.4
–79.8
–78.3
–75.6
–72.7
–
–
–
–
–
–
–
–
–
–
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
