ADVANCE
CYW43570
15.3 WLAN 2.4 GHz Receiver Performance Specifications
Note: The specifications in Table 29 are specified at the RF port unless otherwise specified. Results with FEMs that are not on the
Cypress AVL are not guaranteed.
Table 29. WLAN 2.4 GHz Receiver Performance Specifications
Parameter
Frequency range
Condition/Notes
Min.
2400
Typ.
Max.
2500
Unit
MHz
–
–
RX sensitivity IEEE 802.11ba
1 Mbps DSSS
2 Mbps DSSS
5.5 Mbps DSSS
11 Mbps DSSS
6 Mbps OFDM
9 Mbps OFDM
12 Mbps OFDM
18 Mbps OFDM
24 Mbps OFDM
36 Mbps OFDM
48 Mbps OFDM
54 Mbps OFDM
6 Mbps OFDM
9 Mbps OFDM
12 Mbps OFDM
18 Mbps OFDM
24 Mbps OFDM
36 Mbps OFDM
48 Mbps OFDM
54 Mbps OFDM
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–98.5
–95.4
–93.4
–90.4
–94.4
–93.4
–91.5
–89.3
–86.0
–82.8
–78.4
–77.0
–95.6
–95.4
–94.3
–92.4
–88.9
–85.8
–81.4
–80.0
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
SISO RX sensitivity IEEE 802.11g
(10% PER for 1024 octet PSDU)a
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
MIMO RX sensitivity IEEE 802.11g
(10% PER for 1024 octet PSDU)a
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
dBm/core
SISO RX sensitivity IEEE 802.11n
(10% PER for 4096 octet PSDU)a, b
Defined for default parameters: GT, 800
ns GI, LDPC coding, and non-STBC.
20 MHz channel spacing for all MCS rates
MCS0
MCS1
MCS2
MCS3
MCS4
MCS5
MCS6
MCS7
–
–93.6
–91.0
–88.7
–86.2
–82.7
–78.6
–77.2
–75.4
–
–
–
–
–
–
–
–
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
–
–
–
–
–
–
–
Document Number: 002-15054 Rev. *I
Page 63 of 94
