CUI Devices │ SERIES: CFM-60V │ DESCRIPTION: DC AXIAL FAN
date 02/11/2020 │ page 3 of 15
INPUT
parameter
conditions/description
min
typ
max
units
12 Vdc input models
24 Vdc input models
4.5
8
12
24
13.8
27.6
Vdc
Vdc
operating input voltage1
starting voltage2
12 Vdc input models
24 Vdc input models
4.5
8
Vdc
Vdc
Note:
1. See Model section on page 1 for specific input voltage ranges.
2. Starting voltage for model CFM-6010V-130-205 is 6 Vdc.
PERFORMANCE3
parameter
rated speed
air flow
conditions/description
min
2200
12.2
0.04
10.7
typ
max
5700
30.4
0.31
39.0
units
RPM
at rated voltage, 25°C, after 10 minutes
at 0 inch H2O, see performance curves
at 0 CFM, see performance curves
at 1 m
CFM
static pressure
noise
inch H2O
dBA
Note:
3. See Model section on page 1 for specific values.
PROTECTIONS / FEATURES4
parameter
conditions/description
min
typ
max
units
auto restart
on all models
rotation detector signal
tachometer signal
available on “11” models
available on “20” models
Notes:
4. See Application Notes for details.
SAFETY & COMPLIANCE
parameter
conditions/description
min
typ
max
units
at 500 Vdc between internal stator and positive
lead wire
insulation resistance of frame
dielectric strength
10
MΩ
apply 500 Vac for 1 minute between housing and
positive lead wire
safety approvals
EMI/EMC
UL/cUL 507, TUV (EN 60950-1)
EN 61000-6-1:2007, EN 61000-6-3:2007+A1
at 40°C, 65% RH
life expectancy
RoHS
70,000
hours
yes
ENVIRONMENTAL
parameter
conditions/description
min
-10
-40
typ
max
70
units
°C
operating temperature
storage temperature
70
°C
