KP1210 Series
4PIN PHOTOTRANSISTOR
PHOTOCOUPLER
cosmo
Numbering System
KP1210X Y (Z)
Note:
KP1210 = Part No.
X = Lead form option (1,2,3,6)
Y = CTR rank option (A ~ Z)
Z = Tape and reel option (TLD,TRU)
Option
Description
Packing quantity
2000 units per reel
2000 units per reel
2 (TLD)
2 (TRU)
surface mount type package + TLD tape & reel option
surface mount type package + TRU tape & reel option
long creepage distance for surface mount type package + TLD
tape & reel option
6 (TLD)
6 (TRU)
2000 units per reel
2000 units per reel
long creepage distance for surface mount type package + TRU
tape & reel option
Recommended Pad Layout for Surface Mount Lead Form
2.Long creepage distance
for surface mount type.
4 pin L
1.Surface mount type.
4 pin SMD
Unit : mm
