MGS3
GENERAL SPECIFICATIONS
ISOLATION INPUT-OUTPUT
DC1,500V or AC1,000V 1minute, Cutoff current=10mA, DC500V 1,000MWmin (20 15C)
OPERATING TEMP.,HUMID.AND ALTITUDE -40 to +85C, 20 to 95%RH (Non condensing) (Required derating), 5,000m (16,400feet) max
STORAGE TEMP.,HUMID.AND ALTITUDE -40 to +100C, 20 to d95%RH (Non condensing), 9,000m (30,000feet) max
ENVIRONMENT
2
VIBRATION
10 - 55Hz 98.0m/s (10G), 3minute period, 60minutes each along X, Y and Z axis
2
IMPACT
490.3m/s (50G) 11ms, once each along X, Y and Z axis
SAFETY
OTHERS
AGENCY APPROVALS
CASE SIZE/WEIGHT
COOLING METHOD
UL60950-1, C-UL, EN60950-1
17.0X12.0X8.5mm [0.67X0.48X0.34 inches] (WXHXD) / 4g max
Convection/Forced air
*1 Rated input 5V, 12V, 24V or 48V DC Io=100%
*2 Ripple and ripple noise is measured by using test board with ceramic capacitor 1 F at 50mm from output pins.
*3 Drift is the DC output accuracy for eight hours period after a half-hour warm-up at 25C.
*
*
Parallel operation with other model is not possible.
MGW3xx12/MGW3xx15 is available as single output, +24V/+30V
External view
¶Recommended Pad and Hole dia.
（TOP VIEW）
Model
4-f0.9
<Standard>
Model
5.08
[0.2]
2.2
[0.09]
2.54
[0.1]
2.8
[0.11]
5-f0.9
12.7
[0.5]
<Option :Y2>
－
Vin
＋
Vin
＋
Vout
－Vout
0.5
[0.02]
17
[0.67]
<Pin Configuration (Option :Y2)>
¶Unit : 0.1inch
¶Dimension : mm
¶ Tolerance 0.5 [ 0.02]
¶ Dimensions in mm, [ ]= inches
¶ Pin terminal material : Copper
¶ Planting treatment of terminal : Lead free plating
¶ Case material : PBT
¶ Weight 4g max
2.2
[0.09]
2.54
[0.1]
12.7
[0.5]
－
Vin
＋
Vin
＋Vout TRM －Vout
0.5
[0.02]
17
[0.67]
MG-5
