6.0 Electrical and Timing
Specifications
6.1 Absolute Maximum Ratings
Table 6-1. Absolute Maximum Ratings
Symbol
Parameter
Minimum
Maximum
Units
VCC
VI
Supply Voltage
–0.3
–1.0
7
V
V
Voltage on Any Signal Pin
Storage Temperature
5.3
TST
–40
125
220
°C
°C
TVSOL
Vapor Phase Soldering
Temperature (1 minute)
°C
Thermal Resistance (68 PLCC), Still Air
39.8
θJA
/
W
NOTE(S): Stresses greater than those listed in this table may cause permanent damage to the device. This is a stress rating only.
Functional operation of the device at these or any other conditions beyond those listed in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
6.1.1 Recommended Operating Conditions
Table 6-2. Recommended Operating Conditions
Symbol
Parameter
Minimum
Maximum
Units
VCC
Supply Voltage
3.0
3.6
85
V
TAMB
Ambient Operating Temperature
High-Level Input Voltage
Low-Level Input Voltage
–40
°C
VIH
VIL
2.0
VEXT +.25
0.8
V
V
–0.3
