CS8900A
Crystal LAN™ Ethernet Controller
This section describes buffering and transfer-
ring held receive frames. Section 5.3 on
page 90 through Section 5.5 on page 96 de-
scribe DMAed receive frames.
ting the Skip_1 bit (Register 3, RxCFG, bit
6).
Or:
3) The host reads part of the frame and then
reads the RxEvent register (Register 5), ei-
ther directly or through the ISQ, and learns
of another receive frame. This condition is
called an "implied Skip". Ensure that the
host does not do “implied skips.”
5.2.5 Buffering Held Receive Frames
If space is available, an incoming frame will be
temporarily stored in on-chip RAM, where it
awaits processing by the host. Although this
receive frame now occupies on-chip memory,
the CS8900A does not commit the memory
space to it until one of the following two condi-
tions is true:
Both early interrupts are disabled whenever
there is a committed receive frame waiting to
be processed by the host.
1) The entire frame has been received and
the host has learned about the frame by
reading the RxEvent register (Register 4),
either directly or through the ISQ.
5.2.6 Transferring Held Receive Frames
The host can read-out held receive frames in
Memory or I/O space. To transfer frames in
Memory space, the host executes repetitive
Move instructions (REP MOVS) from Pack-
etPage base + 0404h. To transfer frames in
I/O space, the host executes repetitive In in-
structions (REP IN) from I/O base + 0000h,
Or:
2) The frame has been partially received,
causing either the RxDest bit (Register C,
BufEvent, Bit F) or the Rx128 bit (Register
C, BufEvent, Bit B) to become set, and the with status and length preceding the frame.
host has learned about the receive frame
There are three possible ways that the host
by reading the BufEvent register (Register
can learn the status of a particular frame. It
C), either directly or through the ISQ.
can:
When the CS8900A commits buffer space to a
1) Read the Interrupt Status Queue;
particular held receive frame (termed a com-
2) Read the RxEvent register directly
mitted received frame), no data from subse-
(Register4); or
quent frames can be written to that buffer
space until the frame is freed from commit-
ment. (The committed received frame may or
may not have been received error free.)
3) Read the RxStatus register (PacketPage
base + 0400h).
5.2.7 Receive Frame Visibility
A received frame is freed from commitment by
any one of the following conditions:
Only one receive frame is visible to the host at
a time. The receive frame's status can be read
from the RxStatus register (PacketPage base
1) The host reads the entire frame sequential-
ly in the order that it was received (first byte + 0400h), and its length can be read from the
in, first byte out).
RxLength register (PacketPage base +
0402h). For more information about Memory
space operation, see Section 4.9 on page 73.
For more information about I/O space opera-
tion, see Section 4.10 on page 75.
Or:
2) The host reads part or none of the frame,
and then issues a Skip command by set-
CIRRUS LOGIC PRODUCT DATASHEET
DS271F4
85
