ES1AL THRU ES1JL
SURFACE MOUNT SUPER FAST RECTIFIER
Reverse Voltage - 50 to 600 Volts
Forward Current - 1.0 Ampere
SOD-123FL
Cathode Band
Top View
FEATURES
Glass passivated device
Ideal for surface mouted applications
Low reverse leakage
Metallurgically bonded construction
High temperature soldering guaranteed:
250 C/10 seconds,0.375
(9.5mm) lead length,
5 lbs. (2.3kg) tension
2.8
±
0.1
1.3± 0.15
0.10-0.30
0.6
±
0.25
1.0±
0.2
1.8± 0.1
MECHANICAL DATA
Case:
JEDEC SOD-123FL molded plastic body over passivated chip
Terminals:
Plated axial leads, solderable per MIL-STD-750,
Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:0.0007
ounce, 0.02 grams
3.7
±
0.2
Dimensions in millimeters
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
SYMBOLS
MDD Catalog Number
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at1.0A
Maximum DC reverse current
T
A
=25 C
at rated DC blocking voltage
T
A
=100 C
Maximum reverse recovery time (NOTE 1)
Typical junction capacitance (NOTE 2)
Typical thermal resistance (NOTE 3)
Operating junction and storage temperature range
V
RRM
V
RMS
V
DC
I
(AV)
ES1AL ES1BL
E1B
E1A
ES1CL ES1DL
E1C
E1D
ES1EL
E1E
ES1GL
E1G
ES1JL
E1J
UNITS
VOLTS
VOLTS
VOLTS
Amp
50
35
50
100
70
100
150
105
150
200
140
200
1.0
300
210
300
400
280
400
600
420
600
I
FSM
V
F
I
R
trr
C
J
R
θ
JA
T
J
,
T
STG
0.95
25.0
1.25
5.0
100.0
35
10
85
-55 to +150
1.7
Amps
Volts
µ
A
ns
pF
K/W
C
Note:
1.Measured with IF=0.5A, IR=1A, Irr=0.25A.
2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.
3.PCB mounted on 0.2*0.2" (5.0*5.0mm) coppeer pad area.
MDD ELECTRONIC
