SURFACE MOUNT ALUMINUM ELECTROLYTIC CAPACITORS
MVY
Standard, 105C
MVH
125C
@Endurance
: 105C 1000 to 2000 hours
@Suitable
to fit for downsized equipment
@Solvent-proof
type (see PRECAUTIONS AND GUIDELINES)
@Pb-free
design
low Z
MVK
MVL
MVJ
longer life
?SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(tane)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
-40 to +105C
6.3 to 50V
dc
P20%
(M)
(at 20C, 120Hz)
I=0.01CV or 3MA, whichever is greater.
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
(at 20C after 2 minutes)
6.3V 10V 16V 25V 35V 50V
Rated voltage (V
dc
)
D55 to F55 0.30 0.24 0.20 0.16 0.14 0.12
tanE (Max.)
H63 to JA0 0.40 0.30 0.26 0.16 0.14 0.12
(at 20C,120Hz)
6.3V 10V 16V 25V 35V 50V
Rated voltage (V
dc
)
2
2
2
3
2
4
Z(-25C)/Z(+20C)
3
10
8
6
4
3
Z(-40C)/Z(+20C)
(at 120Hz)
The following specifications shall be satisfied when the capacitors are restored to 20C after the rated voltage is applied for the specified
period of time at 105C.
Case code
D55 to F55
H63 to JA0
Time
1000hours
2000hours
Capacitance change
[P30%
of the initial value
[P20%
of the initial value
D.F. (tanE)
[300%
of the initial specified value
[200%
of the initial specified value
Leakage current
[The
initial specified value
[The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for the specified time at 105C
without voltage applied.
Case code
D55 to F55
H63 to JA0
Time
500hours
1000hours
Capacitance change
[P25%
of the initial value
[P20%
of the initial value
D.F. (tanE)
[200%
of the initial specified value
[200%
of the initial specified value
Leakage current
[The
initial specified value
[The
initial specified value
Characteristics
Shelf Life
?DIMENSIONS
[mm]
@Terminal
Code : A
FDP0.5
BP0.2
W
?MARKING
Size code
D55
E55
F55
H63
HA0
JA0
D
4
5
6.3
8
8
10
L
A
B
C
5.2 4.3 4.3 5.1
5.2 5.3 5.3 5.9
5.2 6.6 6.6 7.2
6.3 8.3 8.3 9.0
10.0 8.3 8.3 9.0
10.0 10.3 10.3 11.0
W
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.5 to 0.8
0.7 to 1.1
0.7 to 1.1
P
1.0
1.4
1.9
2.3
3.1
4.5
EX) 6.3V100MF
7hK
P
CP0.2
100
6.3V
0.3max.
LP0.3 (Note)
Note : LP0.5 for H63 to JA0
AP0.2
?PART
NUMBERING SYSTEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
E MV K
AAA
A DA
AAA
M
AAA
G
Supplement code
Size code
Capacitance tolerance code
Capacitance code (ex. 4.7MF:4R7,10MF:100)
Taping code
Terminal code
Voltage code (ex. 6.3V:6R3,10V:100,50V:500)
Series code
Category
Please refer to "A guide to global code (surface mount type)"
(1/2)
CAT. No. E1001E
