F-Series Circuit Breaker – Dimensional Specifications
Dimensional Specifications: in. [mm]
F-Series breakers are available up to 700A, and are also available with a 25 millivolt metering shunt construction.
This optional construction provides a safe method for monitoring current flowing through the breaker by simply
connecting a meter with light gauge wire to the appropriate terminals located on the shunt housing at the rear of
the breaker. You can customize the application by measuring and displaying percentage of current, watts or safe/
danger zones.
Notes:
1
2
All dimensions are in inches [millimeters].
Tolerance ±.020 [.51] unless otherwise specified.
