13
C-Series Circuit Breaker - Arc Chute Barrier UL Recognized/Listed – Dimensional Specifications
Dimensional Specifications: in. [mm]
Notes:
1
Only 1-pole and 3-pole configurations shown. Arc chute (without barrier) and arc chute
barrier also available for 2-pole construction.
2
3
Dimensions apply to all variations shown.
Notice that line and load terminal orientation for indicate on and indicate off rocker
circuit breakers are opposite.
4
Screw type terminals shown for Rocker style (CF1, C11, etc) circuit breakers. For
other terminal configurations see circuit and terminal diagrams.
All dimensions are in inches [millimeters].
5
6
7
Tolerance ± .020 unless otherwise specified.
Must be ordered under a special catalog number.
