B-Series Circuit Breaker - Rocker UL489 Listed – Ordering Scheme
B F 1 B 0 24 630 2 3 A K G
8
9
10
Mounting/
Barriers
11
12
1
2
3
4
5
6
7
Terminal
Actuator
Color
Max. Appl. Agency
Rating Approval
Series
Actuator
Poles
Circuit
Aux/Alarm
Switch
Frequency
& Delay
Current Rating
5
1 SERIES
8 TERMINAL
6
1
2
3
4
5
6
Push-On 0.250 Tab (Q.C.)
Screw 8-32 with upturned lugs
Screw 8-32 (Bus Type)
Screw 10-32 with upturned lugs
Screw 10-32 (Bus Type)
Screw 8-32 with upturned lugs
& 30° bend
Screw 8-32 (Bus Type)
& 30° bend
Screw 10-32 with upturned lugs
& 30° bend
Screw 10-32 (Bus Type)
& 30° bend
B
C
F
Screw M5 with upturned lugs
Screw M4 with upturned lugs
Screw M5 with upturned lugs
& 30° bend
B
2 ACTUATOR
Two Color Visi-Rocker
G
H
J
K
N
Y
Screw M5 (Bus Type) & 30° bend
Screw M5 (Bus Type)
Single color
C
D
F
Indicate ON, vertical legend
J
Vertical legend
Screw M5 Back Connect
Screw 10-32 Back Connect
Screw M4 Back Connect
Screw 8-32 Back Connect
Indicate ON, horizontal legend
Indicate OFF, vertical legend
Indicate OFF, horizontal legend
K
Horizontal legend
7
8
9
G
9 ACTUATOR COLOR & LEGEND
Actuator or
Marking:
Marking Color
7
7
Visi-Color
ON-OFF
Dual
Single Color Visi-Rocker
White
Black
Red
B
D
G
J
1
2
3
4
5
6
7
8
Black
White
White
White
White
Black
Black
Black
White
n/a
Red
Green
Blue
Green
Blue
L
Yellow
Gray
Orange
N
Q
S
Yellow
Gray
Orange
10 MOUNTING / BARRIERS
1,2
3 POLES
One
9
MOUNTING STYLE
BARRIERS
3
1
2
Two
3
Three
Threaded Insert, 2 per pole
6-32 x 0.195 inches (multi-pole units only)
ISO M3 x 5mm
A
B
yes
yes
4 CIRCUIT
Series Trip (Current)
ROCKERGUARD BEZEL
Threaded Insert, 2 per pole
6-32 X 0.225 inches (multi-pole units only)
ISO M3 x 6.5mm
B
C
D
yes
yes
4
5 AUXILIARY / ALARM SWITCH
0
1
2
3
without Aux Switch
7
S.P.S.T., 0.110 Q.C. Term.
(Gold Contacts)
S.P.S.T., 0.187 Q.C. Term.
S.P.D.T., 0.187 Q.C. Term.
S.P.D.T., 0.093 Q.C. Term.
S.P.D.T., 0.110 Q.C. Term.
S.P.D.T., 0.110 Solder Lug
8
9
11 MAXIMUM APPLICATION RATING
8
C
K
120/240 VAC
120 VAC
6 FREQUENCY & DELAY
21
22
24
26
AC Ultra Short
AC Short
42
44
46
AC, Short, High-inrush
AC, Medium, High-inrush
AC, Long, High-inrush
12 AGENCY APPROVAL
G
3
UL489 Listed
UL489 Listed, TUV Certified
AC Medium
AC Long
Notes:
1
Multi-pole breakers have all breakers identical except when specifying Auxiliary switch
and/or mixed poles, and have one rocker per breaker.
All poles must be same polarity.
7 CURRENT RATING (AMPERES)
CODE AMPERES
2
3
4
5
6
3 pole units available only when 1 of 3 poles is neutral.
On multi-pole breakers, one auxiliary switch is supplied, mounted in the extreme right pole.
Screw Terminals are recommended on ratings greater than 20 amps.
Terminal Code 1 (Push-On) available up to 30 amps, but are not recommended over
20 amps.
020 0.020
025 0.025
030 0.030
035 0.035
040 0.040
045 0.045
050 0.050
055 0.055
060 0.060
065 0.065
070 0.070
075 0.075
080 0.080
085 0.085
090 0.090
095 0.095
210 0.100
215 0.150
220 0.200
225 0.250
230 0.300
235 0.350
240 0.400
245 0.450
250 0.500
255 0.550
260 0.600
265 0.650
270 0.700
275 0.750
280 0.800
285 0.850
290 0.900
295 0.950
410 1.000
512 1.250
415 1.500
517 1.750
420 2.000
522 2.250
527 2.750
430 3.000
435 3.500
440 4.000
445 4.500
450 5.000
455 5.500
460 6.000
465 6.500
470 7.000
475 7.500
480 8.000
485 8.500
490 9.000
495 9.500
610 10.000
710 10.500
611 11.000
711 11.500
612 12.000
712 12.500
613 13.000
614 14.000
615 15.000
616 16.000
617 17.000
618 18.000
620 20.000
622 22.000
624 24.000
625 25.000
630 30.000
7
8
9
Dual legend = ON-OFF/I-O
Voltage Rating available with 2 and 3-pole breakers only.
Barriers supplied on multi-pole units only.
