IA
Features
Applications
NT
High resistance to heat and humidity
Resistance to mechanical shock and
pressure
Accurate dimensions for automatic
surface mounting
Wide impedance range
Power supply lines
IC power lines
Signal lines
*R
oH
S
CO
M
PL
MH Series High Current Chip Ferrite Beads
Electrical Specifications
Impedance
(Ω)
at 100 MHz
70 ±25 %
80 ±25 %
120 ±25 %
130 ±25 %
150 ±25 %
680 ±25 %
1300 ±25 %
60 ±25 %
75 ±25 %
80 ±25 %
1000 ±25 %
19 ±25 %
26 ±25 %
31 ±25%
50 ±25 %
80 ±25 %
120 ±25 %
150 ±25 %
300 ±25 %
470 ±25 %
500 ±25 %
600 ±25 %
30 ±25 %
52 ±25 %
65 ±25 %
90 ±25 %
150 ±25 %
200 ±25 %
7 ±25 %
10 ±25 %
30 ±25%
80 ±25 %
120 ±25 %
150 ±25 %
220 ±25 %
300 ±25 %
470 ±25 %
600 ±25 %
30 ±25 %
80 ±25 %
120 ±25 %
150 ±25 %
220 ±25 %
300 ±25 %
470 ±25 %
600 ±25 %
RDC
(mΩ)
Max.
30
10
50
40
20
30
60
10
25
50
150
40
40
40
25
30
100
100
200
200
40
100
50
50
30
100
20
30
30
30
25
40
100
100
100
200
200
200
60
40
100
100
100
200
200
200
IDC
(A)
Max.
6.0
6.0
3.0
3.0
5.0
4.0
3.0
6.0
3.0
3.0
1.5
3.0
3.0
3.0
3.0
3.0
2.0
2.0
1.0
1.0
3.0
2.0
3.0
3.0
3.0
2.0
5.0
4.0
3.0
3.0
3.0
3.0
2.0
2.0
2.0
1.0
1.0
1.0
1.0
3.0
2.0
2.0
2.0
1.0
1.0
1.0
General Specifications
Operating Temperature
...................................-55 °C to +125 °C
Storage Temperature ..-55 °C to +125 °C
Storage Condition
......................+40 °C max. at 70 % RH
Reflow Soldering
......................230 ˚C, 50 seconds max.
Resistance to Soldering Heat
.................................260 ˚C, 5 seconds
Rated Current ..................Based on max.
temperature rise of +40 °C
Terminal Strength
(Force “F” applied for 30 seconds)
4532 Series ............................1.5 F (Kg)
4516 Series ............................1.0 F (Kg)
3261 Series ............................1.0 F (Kg)
3225 Series ............................1.0 F (Kg)
2029 Series ............................0.6 F (Kg)
1608 Series ............................0.5 F (Kg)
Materials
Core Material .................................Ferrite
Internal Conductor ...............Ag or Ag/Pd
Terminal .....................................Ag/Ni/Sn
Model Number
MH4532-700Y
MH4532-800Y
MH4532-121Y
MH4532-131Y
MH4532-151Y
MH4532-681Y
MH4532-132Y
MH4516-600Y
MH4516-750Y
MH4516-800Y
MH4516-102Y
MH3261-190Y
MH3261-260Y
MH3261-310Y
MH3261-500Y
MH3261-800Y
MH3261-121Y
MH3261-151Y
MH3261-301Y
MH3261-471Y
MH3261-501Y
MH3261-601Y
MH3225-300Y
MH3225-520Y
MH3225-650Y
MH3225-900Y
MH3225-151Y
MH3225-201Y
MH2029-070Y
MH2029-100Y
MH2029-300Y
MH2029-800Y
MH2029-121Y
MH2029-151Y
MH2029-221Y
MH2029-301Y
MH2029-471Y
MH2029-601Y
MH1608-300Y
MH1608-800Y
MH1608-121Y
MH1608-151Y
MH1608-221Y
MH1608-301Y
MH1608-471Y
MH1608-601Y
*RoHS Directive 2002/95/EC Jan 27 2003 including Annex
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
