Termination Rear Connection Durability: 200 cycles
Cable/Connector Retention:
Connector/Hardware Retention:
Plug/Connector Retention:
25 lbs.
20 lbs
11.250 lbs
Standards
UL Rating:
UL94V-0
Telecommunications Standards:
Category 6A - TIA 568.C.2, Category 6A - ISO/IEC 11801:2002 Ed.2
Power Over Ethernet (PoE) IEEE 802.3at type 1 and 2 (up to 30W), IEEE802.3bt/D1.7 type 3 and 4 (up to 100W), CISCO UPOE (up to 60W), Power over
HDBaseTTM (up to 100W)
IEEE Specification:
Other Specification:
UL 1863, IEC 60603-7, FCC part 68-F
Applicable Environmental and Other Programs
EU Directive 2002/95/EC (RoHS):
Yes
EU RoHS Compliance Date
(yyyy-mm-dd):
2006-07-01
MII Order #39 (China RoHS):
EUP 50
Flammability, LS0H, Toxicity Testing
UL Flammability:
Safety Listing:
UL2043 Air Handling Spaces
c(UL)us Listed
Part Number
Related Parts:
Compatible with Shielded KeyConnect Patch Panels 24p and 48p, Compatible with KeyConnect Faceplates, Adapters, Boxes
Variants
Item #
Color
RVAIJ2SME-B24 Metal
RVAIJ2SME-S1 Metal
Product Notes
Notes:
Please see Installation Guide PX106884.
History
Update and Revision:
Revision Number: 0.10 Revision Date: 05-02-2019
