63 Ohm
Current
Max. Recommended Current [A]
40 Amps per conductor @ 30°C (per NEC)
Voltage
UL Voltage Rating
Voltage Rating [V]
1000 V RMS (Flexible Motor Supply Cable) 1000 V RMS (CSA AWM I/II A/B)
600 V RMS (Type TC)
Temperature Range
UL Temp Rating:
90°C Dry, 90°C Wet
-40C To +90C Wet/Dry
-40°C To +90 °C
Operating Temp Range:
Wet Temp Range:
Dry Temp Range:
-40°C To +90 °C
Mechanical Characteristics
Bulk Cable Weight:
350 lbs/1000ft
592 lbs
Max Recommended Pulling Tension:
Min Bend Radius/Minor Axis:
5.5 in
Standards
NEC Articles:
336 - ER
NEC/(UL) Specification:
CEC/C(UL) Specification:
CSA AWM Specification:
PMSHA Specification:
Other Specification:
TC-ER, RHW-2, WTTC
600V Type CIC TC
1000 V AWM I/II A/B
P-07-KA070003
1000V UL Flexible Motor Supply
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/96/EC (BFR):
EU Directive 2011/65/EU (ROHS II):
EU Directive 2012/19/EU (WEEE):
EU Directive 2015/863/EU:
EU Directive Compliance:
Yes
Yes
Yes
Yes
Yes
EU Directive 2003/11/EC (BFR)
Yes
EU CE Mark:
EU RoHS Compliance Date (yyyy-mm-dd): 2005-10-13
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Yes
Yes
Suitability
Suitability - Burial:
Yes
Yes
Yes
Yes
Yes
Suitability - Indoor:
Suitability - Oil Resistance:
Suitability - Outdoor:
Suitability - Sunlight Resistance:
Flammability, LS0H, Toxicity Testing
UL Flammability:
CSA Flammability:
IEEE Flammability:
UL voltage rating:
UL1685 UL Loading
FT4
1202, 383 Vertical Tray Flame Test (70,000 BTU)
1000 V RMS (Flexible Motor Supply Cable)
Part Number
Variants
Item #
Color
UPC
Length Footnote
29503 010100 Black 612825136880 100 ft
