NON-ISOLATED DC/DC CONVERTERS
2.4 Vdc - 5.5 Vdc Input, 0.6 Vdc - 3.63 Vdc /6 A Outputs
January 13, 2011
Bel Power, Inc. , a subsidiary of Bel Fuse, Inc.
Output Filtering (continued)
25
20
20
15
10
5
1x10uF External Cap
1x47uF External Cap
2x47uF External Cap
4x47uF External Cap
15
10
5
1x10uF External Cap
1x47uF External Cap
2x47uF External Cap
4x47uF External Cap
0
0
0.5
1
1.5
2
2.5
3
3.5
0.5
1
1.5
2
2.5
3
Output Voltage(Volts)
Output Voltage(Volts)
Figure A Output ripple voltage for various output
Figure B Output ripple voltage for various output voltage
voltage at Vin=5V, 6A load
at Vin=3.3V, 6A load
Safety Considerations
For safety agency approval the power module must be installed in compliance with the spacing and separation
requirements of the end-use safety agency standards, i.e., UL 60950-1, CSA C22.2 No. 60950-1-03, and VDE
0850:2001-12 (EN60950-1) Licensed.
For the converter output to be considered meeting the requirements of safety extra-low voltage (SELV), the
input must meet SELV requirements. The power module has extra-low voltage (ELV) outputs when all inputs
are ELV.
The input to these units is to be provided with a fast-acting fuse with a maximum rating of 6A in the positive
input lead.
