CX5130
https://www.beckhoff.com/cx5130
CX5130-0113
CX5130-0115
CX5130-0120
CX5130-0121
CX5130-0122
CX5130-0123
CX5130-0125
CX5130-0130
CX5130-0135
CX5130-0140
CX5130-0141
CX5130-0142
CX5130-0143
CX5130-0150
CX5130-0155
CX5130-0160
CX5130-0161
CX5130-0162
CX5130-0163
CX5130-0170
CX5130-0175
CX5130-0185
Windows Embedded Compact 7, TwinCAT 2 NC I runtime
Windows Embedded Compact 7, TwinCAT 3 runtime (XAR)
Windows Embedded Standard 7 P 32 bit, no TwinCAT
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 PLC runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 NC PTP runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 NC I runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 3 runtime (XAR)
Windows Embedded Standard 7 P 64 bit, no TwinCAT
Windows Embedded Standard 7 P 64 bit, TwinCAT 3 runtime (XAR)
Windows 10 IoT Enterprise 2016 LTSB 32 bit, no TwinCAT
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 PLC runtime
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 NC PTP runtime
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 NC I runtime
Windows 10 IoT Enterprise 2016 LTSB 64 bit, no TwinCAT
Windows 10 IoT Enterprise 2016 LTSB 64 bit, TwinCAT 3 runtime (XAR)
Windows 10 IoT Enterprise 2019 LTSC 32 bit, no TwinCAT
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 PLC runtime
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 NC PTP runtime
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 NC I runtime
Windows 10 IoT Enterprise 2019 LTSC 64 bit, no TwinCAT
Windows 10 IoT Enterprise 2019 LTSC 64 bit, TwinCAT 3 runtime (XAR)
TwinCAT/BSD, TwinCAT 3 runtime (XAR)
CX51x0-016x: only 4 GB RAM can be used with Windows 10 IoT Enterprise 2019 LTSC 32 Bit
Windows Embedded Compact 7 only supports one CPU core.
Windows Embedded Compact 7 and TwinCAT/BSD require a CFast flash card with a minimum capacity of 20 GB
Other operating systems require a CFast flash card with a minimum capacity of 40 GB.
TwinCAT 3 runtime (XAR) is preinstalled, without licenses. Please order TwinCAT 3 licenses separately from the TwinCAT 3 Price List.
Options
Options
Technical changes reserved
As of 21.06.2021 | Site 3 of 5
