CX5120
https://www.beckhoff.com/cx5120
CX5120-0115
CX5120-0120
CX5120-0121
CX5120-0122
CX5120-0123
CX5120-0125
CX5120-0130
CX5120-0135
CX5120-0140
CX5120-0141
CX5120-0142
CX5120-0143
CX5120-0150
CX5120-0155
CX5120-0160
CX5120-0161
CX5120-0162
CX5120-0163
CX5120-0170
CX5120-0175
CX5120-0185
Windows Embedded Compact 7, TwinCAT 3 runtime (XAR)
Windows Embedded Standard 7 P 32 bit, no TwinCAT
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 PLC runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 NC PTP runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 2 NC I runtime
Windows Embedded Standard 7 P 32 bit, TwinCAT 3 runtime (XAR)
Windows Embedded Standard 7 P 64 bit, no TwinCAT
Windows Embedded Standard 7 P 64 bit, TwinCAT 3 runtime (XAR)
Windows 10 IoT Enterprise 2016 LTSB 32 bit, no TwinCAT
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 PLC runtime
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 NC PTP runtime
Windows 10 IoT Enterprise 2016 LTSB 32 bit, TwinCAT 2 NC I runtime
Windows 10 IoT Enterprise 2016 LTSB 64 bit, no TwinCAT
Windows 10 IoT Enterprise 2016 LTSB 64 bit, TwinCAT 3 runtime (XAR)
Windows 10 IoT Enterprise 2019 LTSC 32 bit, no TwinCAT
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 PLC runtime
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 NC PTP runtime
Windows 10 IoT Enterprise 2019 LTSC 32 bit, TwinCAT 2 NC I runtime
Windows 10 IoT Enterprise 2019 LTSC 64 bit, no TwinCAT
Windows 10 IoT Enterprise 2019 LTSC 64 bit, TwinCAT 3 runtime (XAR)
TwinCAT/BSD, TwinCAT 3 runtime (XAR)
CX51x0-016x: only 4 GB RAM can be used with Windows 10 IoT Enterprise 2019 LTSC 32 Bit
Windows Embedded Compact 7 and TwinCAT/BSD require a CFast flash card with a minimum capacity of 20 GB
Other operating systems require a CFast flash card with a minimum capacity of 40 GB.
TwinCAT 3 runtime (XAR) is preinstalled, without licenses. Please order TwinCAT 3 licenses separately from the TwinCAT 3 Price List.
Options
Options
Device modification for CX5120, CX5130, CX5140 and CX9020 Embedded PCs according to
the requirements for ATEX, IECEx and FM certification. The modification is mandatory for
the usage of CX5120, CX5130, CX5140 and CX9020 in hazardous areas, Zone 2/22
respectively Class I, Div. 2.
It includes the modification and repositioning of the device label as well as a mounting
bracket installed ex works for mechanical locking of the connectors.
Product labeling:
CX2900-0107
ATEX: II 3 G Ex nA IIC T4 Gc and II 3 D Ex tc IIIC T135 °C Dc
IECEx: Ex nA IIC T4 Gc and Ex tc IIIC T135 °C Dc
cFMus: CL I, DIV 2. GP A, B, C, D und CL I, Zn 2 AEx/Ex ec IIC T4 Gc
Read the device documentation for use in hazardous areas carefully.
Technical changes reserved
As of 21.06.2021 | Site 3 of 5
