CP26xx-0000
https://www.beckhoff.com/cp26xx-0000
Ordering Information
CP26xx-0000
CP2607-0000
CP2612-0000
CP2613-0000
CP2615-0000
CP2616-0000
CP2618-0000
CP2619-0000
CP2621-0000
CP2624-0000
Dual-touch built-in Panel PC with ARM Cortex™-A8
7-inch display 800 x 480, dual-finger touch screen
12-inch display 800 x 600, dual-finger touch screen
12.1-inch display 1280 x 800, dual-finger touch screen
15-inch display 1024 x 768, dual-finger touch screen
15.6-inch display 1366 x 768, dual-finger touch screen
18.5-inch display 1366 x 768, dual-finger touch screen
19-inch display 1280 x 1024, dual-finger touch screen
21.5-inch display 1920 x 1080, dual-finger touch screen
24-inch display 1920 x 1080, dual-finger touch screen
Options
Options
Dual-touch built-in Panel PC with ARM Cortex™-A8
vertical orientation of the display inside the Control Panel or Panel PC CP22xx, CP26xx,
CP29xx or CP39xx instead of standard Control Panel or standard Panel PC
C9900-M575
1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A
socket IP 65
C9900-E268
C9900-F941
stainless steel front with blue silicone seal for CP2x07-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x13-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
C9900-F942
C9900-F945
C9900-F946
C9900-F948
stainless steel front with blue silicone seal for CP2x16-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x18-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x21-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
C9900-H800
C9900-H801
C9900-H806
C9900-S706
C9900-S707
2 GB microSD card, instead of 512 MB microSD card
4 GB microSD card, instead of 512 MB microSD card
8 GB microSD card, instead of 512 MB microSD card
TwinCAT 2 PLC runtime for Windows Embedded Compact 7
TwinCAT 2 NC PTP runtime for Windows Embedded Compact 7
internal, capacitive 1-second UPS to ensure secure backup of persistent application data
on the flash card, requires TwinCAT and Windows Embedded Compact 7
C9900-U212
Technical changes reserved
As of 23.06.2021 | Site 3 of 3
