RAID
on-board SATA RAID 1 controller
hard disk, 2½-inch, 320 GB
Hard disks/flash
Interfaces
SSD, CFast
2 x USB 3.0, 2 x USB 2.0, 1 x RS232, 1 x DVI 1 x USB in the front
Power supply
24 V DC
–
UPS
Windows 7, Windows Embedded Standard
7, Windows 10 IoT Enterprise
Operating system
Ordering Information
CP22xx-0010
CP2212-0010
CP2213-0010
CP2215-0010
CP2216-0010
CP2218-0010
CP2219-0010
CP2221-0010
CP2224-0010
Multi-touch built-in Panel PC
12-inch display 800 x 600, multi-finger touch screen
12.1-inch display 1280 x 800, multi-finger touch screen
15-inch display 1024 x 768, multi-finger touch screen
15.6-inch display 1366 x 768, multi-finger touch screen
18.5-inch display 1366 x 768, multi-finger touch screen
19-inch display 1280 x 1024, multi-finger touch screen
21.5-inch display 1920 x 1080, multi-finger touch screen
24-inch display 1920 x 1080, multi-finger touch screen
Options
Options
CP22xx-0010
vertical orientation of the display inside the Control Panel or Panel PC CP22xx, CP26xx,
CP29xx or CP39xx instead of standard Control Panel or standard Panel PC
C9900-M575
1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A
socket IP 65
C9900-E268
C9900-F945
stainless steel front with blue silicone seal for CP2x16-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x18-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
C9900-F946
C9900-F948
stainless steel front with blue silicone seal for CP2x21-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
processor 4th generation Intel® Core™ i3 4100E, 2.4 GHz, 2 cores (TC3: 60), instead of
Intel® Celeron® 2000E 2.2 GHz (TC3: 50)
C9900-C562
C9900-C570
C9900-C563
C9900-C571
processor 4th generation Intel® Core™ i3 4110E, 2.6 GHz, 2 cores (TC3: 60), instead of
Intel® Celeron® 2000E 2.2 GHz (TC3: 50)
processor 4th generation Intel® Core™ i5 4400E, 2.7 GHz, 2 cores (TC3: 70), instead of
Intel® Celeron® 2000E 2.2 GHz (TC3: 50)
processor 4th generation Intel® Core™ i5 4410E, 2.9 GHz, 2 cores (TC3: 70), instead of
Intel® Celeron® 2000E 2.2 GHz (TC3: 50)
Technical changes reserved
