CP27xx-0000
https://www.beckhoff.com/cp27xx-0000
Windows 7, Windows Embedded Standard
7
Operating system
Windows Embedded Compact 7, English
Ordering Information
CP27xx-0000
CP2712-0000
CP2715-0000
CP2716-0000
CP2718-0000
CP2719-0000
CP2721-0000
CP2724-0000
Fanless multi-touch built-in Panel PC
12-inch display 800 x 600, Display only, multi-finger touch screen
15-inch display 1024 x 768, Display only, multi-finger touch screen
15.6-inch display 1366 x 768, Display only, multi-finger touch screen
18.5-inch display 1366 x 768, Display only, multi-finger touch screen
19-inch display 1280 x 1024, Display only, multi-finger touch screen
21.5-inch display 1920 x 1080, Display only, multi-finger touch screen
24-inch display 1920 x 1080, Display only, multi-finger touch screen
Options
Options
CP27xx-0000
1-port USB socket inside the front of a CP2xxx without push-button extension, USB-A
socket IP 65
C9900-E268
stainless steel front with blue silicone seal for CP2x13-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
C9900-F942
C9900-F945
C9900-F946
C9900-F948
stainless steel front with blue silicone seal for CP2x16-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x18-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
stainless steel front with blue silicone seal for CP2x21-00x0 for horizontal alignment,
stainless steel 1.4404, matt ground with grain size 240, instead of standard aluminium
front
memory extension to 4 GB DDR3 RAM, instead of 2 GB, requires a 64 bit operating
system or only 3 GB are addressable
C9900-R249
C9900-R250
memory extension to 8 GB DDR3 RAM, instead of 2 GB, requires a 64 bit operating
system
third on-board Ethernet adapter on the 3½-inch motherboard for Intel Atom® or Intel®
Celeron® ULV 827E 1.4 GHz, wired out with a 100/1000BASE-T connector inside the
connector bracket at the connection section
C9900-B415
1 PCIe module slot integrated inside CP27xx, to plug-in Beckhoff PCIe modules, instead
of 1 connector bracket to lead out interfaces
C9900-B518
C9900-E233
1 serial port RS232 of the motherboard led out at the connection section of a C5210,
C65x5, CP2xxx, CP62xx or CP67xx-xxxx-0040/-0050
2 USB ports of the motherboard led out at the connection section of a C5210, C65x5,
CP2xxx, CP62xx or CP67xx-xxxx-0040/-0050
C9900-E234
C9900-E240
Serial port COM2 RS232, optically linked, overload protection, D-sub 9-pin connector.
Technical changes reserved
As of 23.06.2021 | Site 3 of 4
