High Voltage DIP Leaded (HV Style)
Surface Mount and Thru-Hole HV Styles
CHIP SEPARATION
CHIP SEPARATION
0.254 (0.010) TYP.
0.254 (0.010) TYP.
CAPACITOR
D
E
E
1.651 0.254
(0.065 0.010)
4.191 0.254
(0.165 0.010)
1.397 (0.055)
0.254 (0.010)
R 0.508
(0.020)
3 PLACES
2.540 0.254
(0.100 0.010)
A
B
B
DETAIL A
6.350 (0.250) MIN
0.254
(0.010)
TYP.
0.508 (0.020) TYP.
6.35
(0.250)
MIN.
0.254
(0.010)
TYP.
2.54 (0.100) TYP.
1.016 0.254
(0.040 0.010)
C
C
2.54 (0.100) MAX.
0.635 (0.025) MIN.
DETAIL A
“N” STYLE LEADS
“P” STYLE LEADS
CHIP SEPARATION
0.254 (0.010) TYP.
CHIP SEPARATION
0.254 (0.010) TYP.
D
E
E
0.254 (0.010)
RAD. (TYP.)
0.254 (0.010)
RAD. (TYP.)
1.397 (0.055)
0.254 (0.010)
A
B
0.254 (0.010)
TYP.
0.254 (0.010)
TYP.
1.905 (0.075)
0.635 (0.025)
TYP.
1.905 (0.075)
0.635 (0.025)
TYP.
1.778 (0.070)
0.254 (0.010)
1.778 (0.070)
0.254 (0.010)
0.508 (0.020) TYP.
2.54 (0.100) TYP.
C
C
2.54 (0.100) MAX.
0.635 (0.025) MIN.
“J” STYLE LEADS
“L” STYLE LEADS
CHIP SEPARATION
0.254 (0.010) TYP.
E
D
RAD.
0.254
(0.010)
(TYP)
1.397 (0.055)
0.254 (0.010)
A
B
1.778 0.254
(0.070 0.010)
C
0.508 (0.020) TYP.
2.54 (0.100) TYP.
3.048 0.381
(0.120 0.015)
DETAIL B
2.54 (0.100) MAX.
0.635 (0.025) MIN.
DETAIL B
“Z” STYLE LEADS
millimeters (inches)
No. of Leads
DIMENSIONS
Style
A (max.)
B (max.)
C
.635 ( 0.025)
D
.635 ( 0.025)
E (max.)
per side
HV01
HV02
HV03
HV04
HV05
HV06
53.3 (2.100)
39.1 (1.540)
27.2 (1.070)
10.2 (0.400)
6.35 (0.250)
53.3 (2.100)
10.5 (0.415)
20.3 (0.800)
10.5 (0.415)
10.2 (0.400)
6.35 (0.250)
29.0 (1.140)
54.9 (2.160)
40.7 (1.600)
28.2 (1.130)
11.2 (0.440)
7.62 (0.300)
54.9 (2.160)
4
8
4
4
3
For “N” Style Leads: “A” Dimension Plus 1.651 (0.065)
For “J” & “L” Style Leads: “A” Dimension Plus 2.032 (0.080)
For “P” Style Leads: “A” Dimension Plus 4.445 (0.175)
For “Z” Style Leads: “A” Dimension Plus 3.048 (0.120)
See page 61 for
maximum “A”
Dimension
11
60
