Discoidal MLC
Feed-Through Capacitors and Filters
Discoidal XB / Feed-through XF – C0G
HOW TO ORDER
XB
AVX Style
XB
XF
06
Size
03
04
06
07
08
09
10
14
15
Z
Class
C = NP0
Z = X7R
G
Voltage
D = 63
E = 100
F = 160
G = 250
I = 400
J = 500 (optional)
0104
Capacitance
EIA code
on 3 or 4
digits
K
Tolerance
J = 5%
K = 10%
M = 20%
--
Packaging
-- : bulk
REFERENCES
Type
bm
Terminations
Silver
palladium
OD
Reference
XB..C•....• --
Mechanical Characteristics
ID
e
bm
Ø
CECC 30600
Tinned
silver palladium
XB..C•....• MB
MIL 11015 D
Conformance
Silver
palladium
XF..C•....• --
to
CK12
TYPE
OD
20
(0.787)
min.
e
20
(0.787)
min.
Tinned
silver palladium
XF..C•....• MB
DIMENSIONS
Size
03
04
08
OD
ID
XB/XF
XB/XF...MB
XB
XB...MB
3.8 ± 0.3
4.1 ± 0.4
0.7 ± 0.15
> 0.4
(0.150 ± 0.012) (0.161 ± 0.016) (0.028 ± 0.006) (> 0.016)
3.8 ± 0.3
—
1.2 ± 0.15
—
(0.150 ± 0.012)
(0.047 ± 0.006)
7.9 ± 0.3
8.2 ± 0.4
0.8 ± 0.15
> 0.5
(0.311 ± 0.012) (0.323 ± 0.016) (0.031 ± 0.006) (> 0.020)
bm
min
0.1
(0.004)
0.1
(0.004)
0.2
(0.008)
Ø
(XF)
0.5
(0.020)
—
0.6
(0.024)
millimeters (inches)
e
min
1
1
1
max
See
table
on
page
105
ELECTRICAL CHARACTERISTICS
Dielectric Class
Temperature Coefficient
Climatic Category
Operating Temperature
Rated Voltage (U
R
)
Test Voltage (U
e
)
Tangent of Loss Angle
C < 50 pF
C ≥ 50 pF
Insulation Resistance
C0G
0 ± 30 ppm/°C
-55 / 125 / 56
-55 +125°C
50 to 400V
2.5 U
R
tg
δ
< 1.5
(
150
+ 7
)
10
-4
C
R
tg
δ
< 15(10
-4
)
Ri ≥ 100 GΩ
104
