S.O. DIMM Connectors
Features/Benefits
SERIES 6401
Series 6401 is a right-angle SMT connector, conforming to JEDEC MO-160 standard of
S.O. DIMM.
TECHNICAL SPECIFICATIONS
Application:
RA SMT Plastic Latch DW Voltage:
500V rms/min.
Phosphor Bronze
LCP
Pitch:
Number of Contacts:
Height:
1.27mm (0.050)
72
5.5mm (0.217)
0.5A Max.
125V Max.
25
Contact Material:
Insulator Material:
Operating Temperature: -55ºC~85ºC
Current Rating:
Voltage Rating:
Mating Cycles
95% Max.
JEDEC MO-160
Standard:
SERIES 6402
Series 6402 is a right-angle SMT connector, conforming to JEDEC standard of 8-byte S.O.
DIMM. It is a low cost type connector with plastic latch and has a wide variety of profile height
(4.0/5.2/5.6mm). Memory modules are firmly inserted and locked by two simple latches.
TECHNICAL SPECIFICATIONS
Application:
Pitch:
Number of Contacts:
Height:
RA SMT Plastic Latch Voltage Rating:
25V Max.
0.8mm (0.031)
144
DW Voltage:
Contact Material:
Insulator Material:
1000V rms/min.
Phosphor Bronze
LCP
4.0mm (0.157)
5.2mm (0.205)
5.6mm (0.220)
0.3A Max.
25
Operating Temperature: -55ºC~85ºC
95% Max.
JEDEC MO-190
Current Rating:
Mating Cycles
Standard:
SERIES 6403
Series 6403 is a 144 positions straight SMT connector conforming to JEDEC standard of
8-byte S.O. DIMM and by both SMT and DIP type (Through Hole type).
(1) SMT and DIP are 3.3V and 5.0V type, respectively. They are also available with and with-
out boss.
(2) SMT type, whose attachment locations of metals on the left and right side are asymmet-
rically arranged, is equipped with strain reliefs to improve the peeling strength to the board.
TECHNICAL SPECIFICATIONS
Application:
ST SMT/DIP
0.8mm (0.031)
144
0.3A Max.
25V Max.
1000V rms/min.
25
Contact Material:
Insulator Material:
Phosphor Bronze
LCP
Pitch:
Number of Contacts:
Current Rating:
Voltage Rating:
DW Voltage:
Operating Temperature: -55ºC~85ºC
95% Max.
JEDEC MO-190
Standard:
Mating Cycles
53
