Product Specification
M270DTN01.5
Electrical Characteristics
Absolute Maximum Rating
Parameter damage may occur if exceeding the following maximum rating.
Min.
Symbol
Description
Max.
150
Unit
[mA]
[mA]
Remark
100% duty ratio
0
Is
LED String Current
Duty ratio 10%
Pulse time=10ms
210
Parameter guideline for LED driving is under stable conditions at 25℃ (Room Temperature):
Symbol
Parameter
Min.
Typ.
Max.
Unit
Note
IRLED
LED Operation Current
-
120
[mA]
132
[Volt]
Note 7-1
Note 7-5
Light Bar Operation Voltage
(for reference)
VLB
53.1
-
56.7
64.8
3.6
Operating with
fixed driving
current
Maximum Vs Voltage
Deviation of light bar
[Volt]
Note 7-2
∆Vs
-
[Watt]
Note 7-3
27.2
31.1
-
PBLU
BLU Power consumption (for reference)
LED life Time (Typical)
[Hour]
30,000
LTLED
Note 7-4
Note 7-1: Vs (Typ.) = VF (Typ.) X LED No. (one string);
a. VF: LED chip forward voltage, VF (Min.)=2.95V, VF(Typ.)=3.15V, VF(Max.)=3.6V
b. The same euqation to calculate Vs(Min.) & Vs (Max.) for respective VF (Min.) &
VF(Max.);
31
