Product Specification
M270DTN01.5
Value
Symbol
Unit
Remark
Min.
0.5
0
Typ.
Max.
T1
T2
T3
T4
-
-
-
-
10
50
-
[ms]
[ms]
[ms]
[ms]
500
100
-
Note 6-7
Note 6-8
T5
0
50
[ms]
T6
T7
0
-
-
150
-
[ms]
[ms]
Note 6-8
1000
Note 6-7 : Recommend setting T5 = 0ms to avoid electronic noise when VDD is off.
Note 6-8 : During T5 and T6 period, please keep the level of input LVDS signals with Hi-Z state.
Backlight Unit
Block Diagram
The following shows the block diagram of the 27 inch Backlight Unit. And it includes 72 pcs LED in
the LED light bar. (4 strings and 18 pcs LED of one string).
26
