ATmega64A
the flag. When the I-bit in SREG, OCIE0 (Timer/Counter0 Compare Match Interrupt Enable), and
OCF0 are set (one), the Timer/Counter0 Compare Match Interrupt is executed.
• Bit 0 – TOV0: Timer/Counter0 Overflow Flag
The bit TOV0 is set (one) when an overflow occurs in Timer/Counter0. TOV0 is cleared by hard-
ware when executing the corresponding interrupt handling vector. Alternatively, TOV0 is cleared
by writing a logic one to the flag. When the SREG I-bit, TOIE0 (Timer/Counter0 Overflow Inter-
rupt Enable), and TOV0 are set (one), the Timer/Counter0 Overflow interrupt is executed. In
PWM mode, this bit is set when Timer/Counter0 changes counting direction at 0x00.
14.11.7 SFIOR – Special Function IO Register
Bit
0x20 (0x40)
7
6
–
5
–
4
–
3
ACME
R/W
0
2
1
PSR0
R/W
0
0
PSR321
R/W
0
TSM
PUD
R/W
0
SFIOR
Read/Write
Initial Value
R/W
0
R
0
R
0
R
0
• Bit 7 – TSM: Timer/Counter Synchronization Mode
Writing TSM bit to one activates the Timer/Counter Synchronization mode. In this mode, the
value that is written to PSR0 and PSR321 bits is kept, hence keeping the corresponding pres-
caler reset signals asserted. This ensures that the corresponding Timer/Counters are halted and
can be configured to the same value without the risk of one of them advancing during configura-
tion. When the TSM bit written zero, the PSR0 and PSR321 bits are cleared by hardware, and
the Timer/Counters start counting simultaneously.
• Bit 1 – PSR0: Prescaler Reset Timer/Counter0
When this bit is one, the Timer/Counter0 prescaler will be reset. The bit is normally cleared
immediately by hardware. If this bit is written when Timer/Counter0 is operating in Asynchronous
mode, the bit will remain one until the prescaler has been reset. The bit will not be cleared by
hardware if the TSM bit is set.
110
8160C–AVR–07/09
