ATmega8(L)
Electrical Characteristics – TA = -40°C to 85°C
Note:
Typical values contained in this datasheet are based on simulations and characterization of other AVR microcontrollers manu-
factured on the same process technology. Min and Max values will be available after the device is characterized.
Absolute Maximum Ratings*
*NOTICE:
Stresses beyond those listed under “Absolute
Maximum Ratings” may cause permanent dam-
age to the device. This is a stress rating only and
functional operation of the device at these or
other conditions beyond those indicated in the
operational sections of this specification is not
implied. Exposure to absolute maximum rating
conditions for extended periods may affect
device reliability.
Operating Temperature.................................. -55C to +125C
Storage Temperature..................................... -65°C to +150°C
Voltage on any Pin except RESET
with respect to Ground ................................-0.5V to VCC+0.5V
Voltage on RESET with respect to Ground......-0.5V to +13.0V
Maximum Operating Voltage ............................................ 6.0V
DC Current per I/O Pin ................................................ 40.0mA
DC Current VCC and GND Pins................................. 300.0mA
DC Characteristics
TA = -40C to +85C, VCC = 2.7V to 5.5V (unless otherwise noted)
Symbol
Parameter
Condition
Min
Typ
Max
Units
Input Low Voltage except
XTAL1 and RESET pins
(1)
VIL
VCC = 2.7V - 5.5V
-0.5
0.2 VCC
Input High Voltage except
XTAL1 and RESET pins
(2)
(2)
VIH
VCC = 2.7V - 5.5V
VCC = 2.7V - 5.5V
VCC = 2.7V - 5.5V
0.6VCC
-0.5
VCC + 0.5
Input Low Voltage
XTAL1 pin
(1)
VIL1
VIH1
VIL2
VIH2
VIL3
0.1VCC
Input High Voltage
XTAL 1 pin
0.8VCC
-0.5
VCC + 0.5
0.2 VCC
Input Low Voltage
RESET pin
V
CC = 2.7V - 5.5V
CC = 2.7V - 5.5V
V
Input High Voltage
RESET pin
(2)
V
0.9VCC
-0.5
VCC + 0.5
0.2VCC
Input Low Voltage
RESET pin as I/O
VCC = 2.7V - 5.5V
VCC = 2.7V - 5.5V
(2)
(2)
Input High Voltage
RESET pin as I/O
0.6VCC
0.7VCC
VIH3
VOL
VOH
IIL
VCC + 0.5
Output Low Voltage(3)
(Ports B,C,D)
I
OL = 20mA, VCC = 5V
0.9
0.6
IOL = 10mA, VCC = 3V
Output High Voltage(4)
(Ports B,C,D)
I
OH = -20mA, VCC = 5V
4.2
2.2
IOH = -10mA, VCC = 3V
Input Leakage
Current I/O Pin
Vcc = 5.5V, pin low
(absolute value)
1
µA
Input Leakage
Current I/O Pin
Vcc = 5.5V, pin high
(absolute value)
IIH
1
RRST
Reset Pull-up Resistor
30
80
k
235
