ATmega8535(L)
Datasheet Change
Log for ATmega8535
Please note that the referring page numbers in this section are referring to this docu-
ment. The referring revision in this section are referring to the document revision.
Changes from Rev.
2502E-12/03 to Rev.
2502F-06/04
1. Updated “Reset Characteristics” on page 35.
2. Updated SPH in “Stack Pointer” on page 10.
3. Updated C code in “USART Initialization” on page 147.
4. Updated “Errata” on page 16.
Changes from Rev.
2502D-09/03 to Rev.
2502E-12/03
1. Updated “Calibrated Internal RC Oscillator” on page 27.
2. Added section “Errata” on page 16.
Changes from Rev.
2502C-04/03 to Rev.
2502D-09/03
1. Removed “Advance Information” and some TBD’s from the datasheet.
2. Added note to “Pinout ATmega8535” on page 2.
3. Updated “Reset Characteristics” on page 35.
4. Updated “Absolute Maximum Ratings” and “DC Characteristics” in “Electrical
Characteristics” on page 252.
5. Updated Table 111 on page 255.
6. Updated “ADC Characteristics – Preliminary Data” on page 260.
7. Updated “ATmega8535 Typical Characteristics – Preliminary Data” on page
263.
8. Removed CALL and JMP instructions from code examples and “Instruction
Set Summary” on page 8.
Changes from Rev.
2502B-09/02 to Rev.
2502C-04/03
1. Updated “Packaging Information” on page 12.
2. Updated Figure 1 on page 2, Figure 84 on page 176, Figure 85 on page 182,
Figure 87 on page 188, Figure 98 on page 204.
3. Added the section “EEPROM Write During Power-down Sleep Mode” on page
20.
4. Removed the references to the application notes “Multi-purpose Oscillator”
and “32 kHz Crystal Oscillator”, which do not exist.
5. Updated code examples on page 42.
6. Removed ADHSM bit.
7. Renamed Port D pin ICP to ICP1. See “Alternate Functions of Port D” on page
62.
17
2502FS–AVR–06/04
