AT90PWM2/3/2B/3B
27.11 Current Consumption in Reset and Reset Pulse width
Figure 27-44. Reset Supply Current vs. VCC (0.1 - 1.0 MHz, Excluding Current through the
Reset Pull-up)
RESET SUPPLY CURRENT vs. VCC
EXCLUDING CURRENT THROUGH THE RESET PULLUP
0,18
0,16
0,14
0,12
0,1
5.5 V
5.0 V
4.5 V
4.0 V
0,08
0,06
0,04
0,02
0
3.3 V
3.0 V
2.7 V
0
0,1
0,2
0,3
0,4
0,5
0,6
0,7
0,8
0,9
1
Frequency (MHz)
Figure 27-45. Reset Supply Current vs. VCC (1 - 24 MHz, Excluding Current through the Reset
Pull-up)
RESET SUPPLY CURRENT vs. VCC
EXCLUDING CURRENT THROUGH THE RESET PULLUP
4
5.5 V
3,5
5.0 V
3
4.5 V
2,5
2
4.0 V
1,5
3.3 V
1
0,5
0
3.0 V
2.7 V
0
5
10
15
20
25
Frequency (MHz)
333
4317J–AVR–08/10
