AT90PWM2/3/2B/3B
Figure 19-6. 9 bits communication data access
Data 8:0 8 7
0
EUDR
UDR
19.6.2.3
UDR/EUDR data access from 13 to 17 bits per character
When the EUSART is used in 13, 14, 15, 16 or 17 bits per character mode, the EUDR/UDR reg-
isters are used in combinaison with the RxB8/TxB8 bit for data access.
For 13, 14, 15 or 16 bit character the upper unused bits in EUDR will be ignored by the Transmit-
ter and set to zero by the Receiver. In transmitter mode, the data should be written MSB first.
The data transmission starts when the UDR register is written.
In these modes, the RxB8/TxB8 registers are not used.
Figure 19-7. 13, 14, 15 and 16 bits communication data access
Data 15:0 15
8 7
0
EUDR
UDR
For 17 bit character the seventeenth bit is locate in RxB8 or TXB8 register. In transmitter mode,
the data should be written MSB first. The data transmission starts when the UDR register is
written.
Figure 19-8. 17 bits communication data access
Data 16:0
16 15
8 7
0
RxB8 (receive)
EUDR
UDR
or TxB8 (transmit)
221
4317J–AVR–08/10
