Sets the minimum analog value detected as a high level (‘1’) and the maximum analog
value detected as a low level (‘0’). See Note 3 on page 18.
Notes: 1. Navfreq and Navv registers should not be changed once the navigation mode is
selected. Finger sensitivity refers to the minimum level of information required from a
finger. The sensitivity is linked to the integration time; a longer integration time
enables better sensitivity but does not tolerate fast movement.
2. The navigation frequency is the frequency needed for the reading of one new naviga-
tion frame.
3. The Clickv register should not be changed once the click mode is selected.
Clickctrl Register
Register Name: Clickctrl (7 bits)
Access Type: Read/Write
Function: Click control
b6
b5
b4
b3
b2
b1
b0
CLICKFREQ
(MSB)
CLICKFREQ
(LSB)
CLICKDET
(MSB)
CLICKDET
(LSB)
CLICKCPT
(MSB)
CLICKCPT
CLICKCPT
(LSB)
0
1
0
1
1
0
1
•
CLICKFREQ: Click pixels reading frequency
00: 180 Hz
01: 90 Hz (default value)
10: 60 Hz
11: 45 Hz
Faster frequency enables faster finger click detection. Lower frequency enables higher
sensitivity.
•
CLICKDET: Threshold for selecting the black/white color of a slice
00: more than 7 black/white pixels and less than 5 white/black pixels
01: more than 8 black/white pixels and less than 4 white/black pixels
10: more than 9 black/white pixels and less than 3 white/black pixels
11: more than 10 black/white pixels and less than 2 white/black pixels
•
CLICKCPT: Click detection counter (maximum number of slices read between two
transitions)
000: 5
001: 7
010: 10
011: 12
100: 16
101: 20
110: 25
111: 31
