AT85C51SND3Bx
Figure 147. SPI Master Waveforms (SSCPHA= 0)
SS
(output)
TCHCH
TCLCH
SCK
(SSCPOL= 0)
(output)
TCHCX
TCLCX
TCHCL
SCK
(SSCPOL= 1)
(output)
TIVCH TCHIX
TIVCL TCLIX
MOSI
(input)
MSB IN
BIT 6
LSB IN
TCLOX
TCHOX
TCLOV
TCHOV
MISO
(output)
Port Data
MSB OUT
BIT 6
LSB OUT
Port Data
Note:
SS handled by software using general purpose port pin.
Figure 148. SPI Master Waveforms (SSCPHA= 1)
SS(1)
(output)
TCHCH
TCLCH
SCK
(SSCPOL= 0)
(output)
TCHCX
TCLCX
TCHCL
SCK
(SSCPOL= 1)
(output)
TIVCH TCHIX
TIVCL TCLIX
MOSI
(input)
MSB IN
BIT 6
LSB IN
TCLOV
TCHOV
TCLOX
TCHOX
MISO
(output)
Port Data
MSB OUT
BIT 6
LSB OUT
Port Data
Note:
SS handled by software using general purpose port pin.
15
7632A–MP3–03/06
